New Arrival China Butterfly Control Valve - Electric Actuator Flange Type Butterfly Valves – Zhongfa

Product Detail

Product Display

Product Advantage

Our valve connection standards include DIN, ASME, JIS, GOST, BS etc., it’s easy for customers to choose the suitable valve, help our customers reduce their stock.

Our valve has standard thickness according to GB26640, makes it capable of holding high pressure when needed.

The valve body use GGG50 material, has higher mechanical property, rate of spheroidization more than 4 class, makes the ductility of the material more than 10 percent. Compared to regular cast iron, it can suffer higher pressure.

Our valve seat use imported nature rubber, with more than 50% of rubber inside. The seat has a good elasticity property, with long service life. It can be open and close more than 10,000 times with no damage for the seat.

The valve seat is wide edge seat, sealing gap is wider than regular type, makes the sealing for connection easier. Wider seat also easy to install than narrow seat. The stem direction of the seat has lug boss, with O ring on it, archive the second sealing of the valve.

The valve seat with 3 bushing and 3 O ring, helps supporting the stem and guarantee the sealing.

Each valve should be cleaned by ultra-sonic cleaning machine, in case of contaminant left inside, guarantee the cleaning of the valve, in case of pollution to the pipeline.

The valve body use high adhesive force epoxy resin powder, helps it adhere to the body after melting.
